    EverSolo DAC-Z6 Digital to Analog Converter (DAC) - ES9068 DAC MQA Decoder Qualcomm

    EverSolo DAC-Z6 Digital to Analog Converter (DAC) - ES9068 DAC MQA Decoder Qualcomm

    Rs. 0.00
    Rs. 0.00
    Sale Sold out
    \n
    \n

    Description

    \n
    \n
    \n
    \n
    \n \n  \n

    EverSolo DAC-Z6 Digital to Analog Converter (DAC) - ES9068 DAC MQA Decoder Qualcomm

    \nFunctional overview \n
      \n
    • Dual ES9068 D\A converter chip, independent decoding for dual channel.
      • \n
    • The 3rd generation XMOS XU316 with higher performance and faster speed.
      • \n
    • High precision, low jitter dual clock oscillators synchronous processing.
      • \n
    • Up to DSD512 Native, PCM768Hz@32Bit decoding.
      • \n
    • Optical, Coaxial and USB support MQA full decoding and rendering.
      • \n
    • Qualcomm QCC5125 Bluetooth 5.0 module, APTX HD/LDAC protocol.
      • \n
    • Fully balanced audio architecture, differential amplifier circuit and professional calibration.
      • \n
    • High-performance headphone amp output, 16-300 ohm headphone driver.
      • \n
    • 3-inch LCD screen, with diverse VU meter modes.
      • \n
    • Low ripple power supply to ensure a purer power source.
      • \n
    • Exclusive mobile phone controller APP for global control.
      • \n
    \n
    \n
    \n
    \n

    Additional Information

    \n
    \n
    \n
    \n
    \n \n  \n

    Specifications

    \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n
    \n
    Model
    		EverSolo DAC-Z6
    \n
    Display Screen
    		3-inch LCD screen
    \n
    Chassis
    		Aluminum Alloy
    \n
    DAC Audio
    		ES 9068*2
    \n
    Audio Processor
    		XMOS XU316
    \n
    OPA Chip
    		RT 6863*6
    \n
    Power Supply
    		high quality switching power supply with low noise
    \n
    Bluetooth Audio Input
    		Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC/aptX/aptX LL/aptX HD/LDAC Bluetooth protocol
    \n
    USB-B DAC Input
    		Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA
    \n
    USB-C DAC Input
    		Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA
    \n
    OPTICAL Audio Input
    		Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA
    \n
    COAXIAL Audio Input
    		Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA
    \n
    Analog Audio Output
    		Preamp output: XLR(balanced)+RCA, Headphone output: 6.3mm single-ended
    \n
    USB Port
    		USB2.0*1（only for firmware upgrade）
    \n
    Control Methods
    		Remote control, Mobile APP control, Knob control
    \n
    Headphone Impedance
    		16-300Ω (low gain mode:16-32Ω/high gain mode:32-300Ω)
    \n
    XLR Audio Output
    		Output Level(Vrms)：4.1Vrms@0dBFS \nTHD+N@A-wt：0.000094%@1kHz（-120dB@1kHz） \nTHD+N@No-wt：0.000117%@1kHz（-118dB@1kHz） \nNoise@No-wt ：<3uVrms \nSNR)@No-wt：125@1kHz \nfrequency response：20Hz-20kHz(±0.15dB) \nCROSSTALK：-123dB@1kHz \nDNR)@No-wt：125dB@1kHz
    \n
    RCA Audio Output
    		Output Level(Vrms)：2.1Vrms@0dBFS \nTHD+N@A-wt：0.000116%@1kHz(-118dB@1kHz) \nTHD+N@No-wt：0.000138%@1kHz(-117dB@1kHz) \nNoise@No-wt ：<2.5uVrms \nSNR)@No-wt：21dB@1kHz \nfrequency response：20Hz-20kHz(±0.15dB) \nCROSSTALK：-118dB@1kHz \nDNR)@No-wt：121dB@1kHz
    \n
    Headphone (low gain mode)
    		Output Level(Vrms)：1.2Vrms@0dBFS \nMax Power：： 45 mW@32Ω \nTHD+N@A-wt：0.00028%@1kHz(-111dB@1kHz) \nTHD+N@No-wt：0.00031%@1kHz(-110dB@1kHz) \nNoise@No-wt ：<3.5uVrms \nSNR)@No-wt：114dB@1kHz \nfrequency response：20Hz-20kHz(±0.15dB) \nDNR)@No-wt：114dB@1kHz
    \n
    Headphone (high gain mode)
    		Output Level(Vrms)：2.8Vrms@0dBFS \nMax Power： 26 mW@300Ω \nTHD+N@A-wt：0.00014%@1kHz(-117dB@1kHz) \nTHD+N@No-wt：0.00016%@1kHz(-116dB@1kHz) \nNoise@No-wt ：<3.5uVrms \nSNR)@No-wt：121dB@1kHz \nfrequency response：20Hz-20kHz(±0.15dB) \nDNR)@No-wt：121dB@1kHz
    \n
    Power Input
    		AC 110~240V 50/60Hz
    \n
    Rated power
    		9W
    \n
    Product Dimensions
    		270mm(W) * 187mm(D)* 50mm(H)
    \n
    Accessories
    		Remote control*1, Power cable*1, User manual*1
