Magnat ICP 52 – 2-Way Recessed Ceiling Speaker
Interior ICP 52
2-WAY RECESSED CEILING SPEAKER
- Excellent sound, even in surroundings that are not ideal in acoustic terms
- High-quality crossover with 3-stage level adjustment for the treble range
- 35° swivelling 19 mm PET dome tweeter for perfect adjustment to any application
- Specially coated membranes, also suitable for use in wet rooms
- 130 mm hairline polypropylene subwoofer with long excursion rubber surround for maximum deflection
2-way recessed ceiling speaker
The ICP 52 is the smallest recessed ceiling speakers of the Interior Performance series. Equipped with a 19 mm tweeter than can be pivoted by 35° in all directions, the in-ceiling system can also be adapted to very custom installation scenarios. As a result, most installation situations can be handled successfully.
Thanks to the coated surface of the cone and high-quality components, installation in humid areas such as in bathroom or near a swimming pool is no problem. In addition, installation with the help of the rugged clamping mechanism is easy.
High flexibility thanks to swivel tweeter
The use of flush-fitting speakers is generally subject to very individual requirements, which is why these products have to offer a high degree of flexibility with regard to to installation. The models fitted with a tweeter can be swivelled 35° in any direction, for example. Thanks to this “swivel technology”, most installation situations can be handled successfully.
Specifications
PRINCIPLE
|
2-way in-wall/in-ceiling loudspeaker |
---|---|
DRIVERS
|
19 mm tweeter 5.25” woofer |
POWER HANDLING (RMS/MAX.)
|
60 / 100 watts |
SENSITIVITY (2.8V/1M)
|
89 dB |
IMPEDANCE
|
8 Ohms |
FREQUENCY RESPONSE
|
38 – 24000 Hz |
CROSSOVER FREQUENCIES
|
4.000 Hz |
RECOMMENDED AMPLIFIER OUTPUT
|
20 – 120 Watts |
OUTER DIMENSIONS Ø
|
202 mm |
CUTTING OUT Ø
|
168 mm |
MOUNTING DEPTH
|
81 mm |
WEIGHT
|
1.0 kg |
