KEF R2C Centre Speakers (Unit)

KEF R2C

The KEF R2C Centre Speaker is a three-way closed-box design that brings clarity and precision to the center channel of your audio setup. With a Uni-Q Array featuring a 1″ vented aluminum dome for high frequencies (HF), a 5″ aluminum cone for the midrange (Mid), and two 130mm hybrid aluminum drivers for the low frequencies (LF), the speaker achieves a harmonious sound reproduction. Operating within a frequency range of 64Hz to 50kHz (-6dB) and delivering a typical bass response down to 49Hz (-6dB), it covers a broad spectrum for detailed audio. The speaker’s dimensions are complemented by crossover frequencies set at 400Hz and 2.9kHz, allowing each driver to handle specific frequency ranges efficiently. With a sensitivity of 87dB (2.83V/1m) and a nominal impedance of 8Ω (min 3.2Ω), the R2C is compatible with a variety of amplifiers, and its recommended power range is 15-200W. The maximum output of 110dB ensures impactful audio, while harmonic distortion is kept below 0.3% for a clean and immersive listening experience.

 Key Features

1. Driver Material: The speaker features a Uni-Q Array with a 1″ vented aluminum dome for high frequencies (HF), a 5″ aluminum cone for the midrange (Mid), and two 130mm hybrid aluminum drivers for low frequencies (LF).
2. SPL Levels: With a sensitivity of 87dB (2.83V/1m), the R2C efficiently converts power into sound, making it suitable for various listening environments.
3. Impedance Rating: The nominal impedance is 8Ω (min 3.2Ω), providing compatibility with a range of amplifiers.
4. Speaker Type: It is a three-way closed-box design, ensuring precise and controlled sound reproduction.
5. Crossover Frequency: The speaker has crossover frequencies set at 400Hz and 2.9kHz, optimizing each driver’s performance in specific frequency ranges.
6. Frequency Range: Operating within a frequency range of 64Hz to 50kHz (-6dB), the speaker covers a broad spectrum for detailed and immersive audio.
7. Bass Response: The typical bass response reaches down to 49Hz (-6dB), delivering impactful low frequencies.
8. Frequency Response: The overall frequency response is 74Hz-28kHz (±3dB), providing a balanced and accurate representation of audio.
9. THD (Total Harmonic Distortion): Harmonic distortion is kept below 0.3% from 120Hz to 28kHz (90dB, 1m), ensuring clean and distortion-free sound.
10. Maximum Output: With a maximum output of 110dB, the R2C can deliver powerful and dynamic audio, making it suitable for home theater setups.

Specifications
