Description
Eversolo DMP-A6 Master Edition – Digital Audio Music Streamer
Functional overview
- Solid aluminium alloy chassis, brushed panel.
- Quad-core ARM Cortex-A55 professional processor.
- 6″ large LCD colour touchscreen, easy control.
- Based on Android 11, deeply tailored system.
- 4GDDR+32GeMMC large memory for masses of applications.
- Support M.2 NVME 3.0 SSD (not included), up to 4TB.
- 2xES9038Q2M DAC for independent stereo decoding.
- Support DSD512 Native, PCM768KHz@32Bit, MQA full decoding.
- The 3rd generation XU316 for higher performance and processing speed.
- Low-jitter dual clock synchronous processing with higher accuracy.
- Fully balanced circuit, XLR balanced and RCA single-ended hi-fi pre-out.
- 2x DOH chips, support HDMI DSD Native and D2P multi-channel output(Up to 5.1).
- Qualcomm QCC5125 Bluetooth 5.0 module with APTX HD.
- Low noise, high quality power supply, providing pure power source for audio circuits.
- Support mastering audio formats DSD (.dsf/.dff/.iso/.dst), APE, FLAC, WAV, MQA, etc.
- Support 2-channel and Multi-channel Gapless playback(FLAC,WAV)
- Personalised music management, lyric matching and music data matching.
- EOS audio engine developed by Eversolo, globally bypassing SRC restrictions.
- Support Direct audio in 3rd party APPs (Apple Music hi-res direct output).
- Full decoding and rendering support for MQA on Optical, Coaxial and USB input etc.
- Support USB, Optical, Coaxial, HDMI digital audio Bit-perfect output.
- Support external USB optical drive for CD disc playback and CD ripping.
- Music services Tidal, Qobuz, Highresaudio, Amazon etc.
- Support Roon ready, Tidal Connect, etc.
- Support music playback from DLNA.
- Support NFS, SMB, Web DAV, UPnP protocols to access storage devices shared in the LAN.
- Support built-in SMB network media sharing service for easy local media sharing.
- Exclusive mobile APP for Android/IOS mobile phones and tablets.
Additional Information
Specifications
|
Model
|
EVERSOLO DMP-A6 |
|---|---|
|
Display
|
6″ LCD touchscreen |
|
Internal Memory
|
4GDDR4 +32GeMMC |
|
DAC
|
ES 9038Q2M*2 |
|
Audio Processor
|
XMOS XU316 |
|
Op-amp Chip
|
OPA1642 |
|
Power Supply
|
Low noise, high quality switching power supplies |
|
SSD
|
M.2 NVME 3.0 2280 protocol, up to 4TB |
|
USB-A Port
|
USB3.0*2 |
|
Ethernet
|
RJ-45(10/100/1000Mbps) |
|
WiFi
|
WiFi 2.4G+5G dual band |
|
Playback and DAC Decoding
|
Support up to stereo DSD512, PCM 768KHz 32Bit, MQA |
|
Music Service
|
Tidal, Qobuz, Highresaudio, Amazon, WebDAV, UPnP |
|
Streaming
|
Air Play, DLNA, Spotify, Tidal Connect, Qobuz Connect etc. |
|
Bluetooth Audio Input
|
BLuetooth BT5.0, support SBC/AAC/aptX/aptX LL/aptX HD/LDAC |
|
USB-C Audio Input
|
USB Audio Compatibility: Windows (7, 10), Mac, Android, IOS Support up to stereo DSD512, PCM 768KHz 32Bit, MQA |
|
Optical/Coaxial Audio Input
|
Support up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA |
|
Optical/Coaxial Audio Output
|
Support up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA |
|
HDMI Audio Output
|
DSD64 Native multi-channel/PCM192KHz multichannel raw output(Up to 5.1) |
|
Control Method
|
Mobile App, Touch screen control |
|
LR Output Audio Characteristics
|
Output level: 5.2V Frequency response: 20Hz~20KHz(±0. 15dB) Dynamic range: > 128dB SNR: >128dB THD+N: <0.00009%(-120dB) @A-wt Crosstalk: >-125dB |
|
RCA Output Audio Characteristics
|
Output level: 2.6V Frequency response: 20Hz~20KHz (±0. 2dB) Dynamic range: > 124dB SNR: >124dB THD+N: <0.00011%(-119dB)@A-WT Crosstalk: >-124dB |
|
PSU
|
AC 110~240V 50/60Hz |
|
Rated Power
|
13W |
|
Dimensions
|
L 187mm* W 270mm* H 90mm |
|
Packing List
|
Power cable*1, USB cable*1，Screwdriver*1，user manual*1 |
